AllStar is a network of Amateur Radio repeaters, remote base stations and hot-spots accessible to each other via Voice over Internet Protocol. It is based on the open source Asterisk a powerful system capable of controlling one or more radios. It provides linking of these radio “nodes” to other systems of similar construction anywhere in the world via VoIP.
Basic Commands you can send to the Node are as follows:
MB7IHI is a simplex Node so commands can only be sent when the node in receiving.
*3 <Node Number> connect to Allstar node
*33 <Node Number> connect to EchoLink node
*73 Disconnect
*70 what is connected?
*80 play ID
*81 play the time
Short Cuts (used to move the Repeater around the Networks)
*51 disconnect and move to NWAG (North West Analogue Group Website)
*52 disconnect and move to FreeStar (FreeStar Allstar Network)
*53 disconnect and move to GB3PI (Cambridge Repeater Group)
*54 disconnect and move to CQUK (Fusion Network with access from Allstar)
*55 disconnect and move to HubNet (Hubnet Website)
*56 disconnect and move to Extended Freedom Network (EFN Website)
*57 disconnect and move to CQ Cumbria GB3CU (CQ-Cumbria Website)
Local Interest Links
*58 Not Currently Assigned
*59 Not Currently Assigned
